Mosquito Screens for Bi-Fold Doors
A bi-fold folds like a concertina and stacks to one side, opening the span completely. That is exactly why an ordinary screen does not fit: what needs covering is the whole opening, not one leaf. Pleated or motorised across the full width.
01THE WHOLE SPAN HAS TO BE CLOSED
With a bi-fold stacked open, several metres stay clear, and that is one panel of fabric rather than a leaf.
02A PLEATED SCREEN READS AS ONE PIECE
The fabric gathers with the same logic as the door itself and needs no room for a leaf. That is the main reason bi-folds get pleated screens.
03A MOTOR BUYS QUALITY OF TRAVEL, NOT COMFORT
Pulling fabric evenly across several metres by hand is not easy. A motor removes both the middle post and the effort.
04THE COMMONEST CAUSE OF REWORK
- The stacked leaves occupy space at the reveal
- The screen cassette cannot go there: it will not open, or it will knock against the door
- This is checked at the survey, not from figures sent over
- A bi-fold threshold is recessed — the screen track has to be just as flat
Bi-folds are standard on Dubai villas and simultaneously the most awkward opening for a screen. When the door is folded away, several metres of clear span remain, and it has to be closed with a single sheet.
Pleated copes because it folds into a narrow cassette itself and needs no room for a leaf to swing. The fabric is drawn across the opening and gathers in a concertina with the same logic as the door. Visually it reads as one piece, and that is the main reason bi-folds get pleated screens.
A motorised screen solves the same problem without a post in the middle and without effort. Pulling several metres of fabric straight by hand is not easy, and the motor earns its place here on quality of travel rather than convenience.
A separate point about the stack of folded leaves. When the bi-fold is open, the leaves occupy the reveal on one side. The screen cassette cannot go there: it will either not open or start rubbing against the door. That is checked at the survey, and it is the most common cause of rework when a screen is ordered to dimensions without a visit.
The threshold on a bi-fold is usually recessed. The screen's bottom guide has to be equally flat, otherwise the point of the level floor is lost.
Sizes and limits
| Parameter | Value |
|---|---|
| What is covered | the whole span, not a leaf |
| Options | pleated or motorised |
| Cassette | clear of the folded stack |
| Warranty | 2 years |
A bi-fold is the standard of Dubai villas and at the same time the most awkward opening for a screen: the whole span has to be closed, not one leaf.
Common questions
Why not an ordinary sliding screen?
A bi-fold opens the whole span; a sliding screen covers it in sections and leaves posts.
Where does the cassette go?
On the opposite side to the folded stack. That is checked at the survey.
Is a threshold necessary?
No. A flat guide keeps the level floor intact.
